| 型号 Model | SL-3A | SL-5A | SL-10A | SL-15A | SL-20A | SL-30A | SL-40A | SL-50A | SL-60A | |
| 制冷机 Refrigeration capacity | Kw | 10 | 15 | 30 | 45 | 60 | 90 | 120 | 150 | 180 |
| Kcal/h | 7740 | 12900 | 25800 | 38700 | 51600 | 77400 | 103200 | 129000 | 154800 | |
| 压缩机 输出功率 Compressor Inputpower |
Kw | 2.2 | 3.7 | 7.5 | 11 | 15 | 22.5 | 30 | 37.5 | 45 |
| HP | 3 | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 60 | |
| 冷冻媒体 类型/Type Refrigerant 填充量/Filling quantity |
R22 | |||||||||
| Kg | 1.5 | 2.5 | 5 | 7.5 | 10 | 12 | 18 | 30 | 35 | |
| 水箱容量 Water tank capacity |
L | 60 | 90 | 180 | 270 | 360 | --- | --- | --- | --- |
| 蒸发器类型Evaporator type | 盘管式 Serpentine pipe type 壳管式 Shell type | |||||||||
| 冷冻水管径 Freezing water pipe | Inch | 1 | 1 | 1.5 | 2 | 2 | 3 | 3 | 4 | 4 |
| 冷冻水流量 Freezing water flow rate |
L/min | 60 | 90 | 180 | 270 | 270 | 270 | 380 | 460 | 550 |
| M³/h | 3.6 | 5.4 | 11 | 16 | 16 | 16 | 23 | 28 | 33 | |
| 风扇 类型/Type Fan motor 功率/Power |
轴流式风机 Axial flow type blower fan | |||||||||
| Kw | 0.45 | 0.45 | 0.45x2 | 0.65x2 | 0.65x2 | 0.65x4 | 0.65x4 | 1.1x2 | 1.8x4 | |
| 安全保护Safeguard | 高低压保护、压缩机过载保护、水泵过载保护 水泵过载保护、防冻保护、流量保护、高低压保护、压缩机过载保护 Protection of high & low pressure, Protection of high & low pressure,compressor overload, Compressor overload,pump overload pump overload,antifreezing,flow rate |
|||||||||
| 电源Power | AC3+N+PE50/60Hz | |||||||||
| 外形尺寸Dimensions(mm) | L | 750 | 1100 | 1450 | 2200 | 2200 | 2200 | 2500 | 2200 | 3000 |
| W | 680 | 680 | 790 | 1000 | 1320 | 1320 | 1200 | 2000 | 2200 | |
| H | 900 | 1100 | 1120 | 2100 | 2100 | 2180 | 2290 | 2180 | 2180 | |
| 质量Weight | Kg | 100 | 160 | 300 | 700 | 750 | 1400 | 1600 | 2200 | 2400 |
| 注： 制冷能力工况： 冷冻水入口温度12℃ 空气侧入口(环境温度)35℃ |
Note: The working conditions for refrigeation: Freezing water inlet temperature is 12℃,and the outlet temperature is 7℃ Air side inlet (envirnmental temperature) is 35℃ |
|||||||||
