| 型号 Model |
高温度 Max Temp℃ |
电热 Heat (kw) |
泵浦功率 Pump (kw) |
流量 Flux L/min |
加热媒介 Heating Medium |
冷热方式 Cooling Mode |
模具接头 Mold Tie (Inch) |
外型尺寸 External Dimensions (L*W*H) |
重量 Weight (kg) |
| STC-6W | 95 | 6 | 0.37 | 45 | 3/8*2*2 | 780*260*650 | 65 | ||
| STC-9W | 95 | 9 | 0.75 | 56 | 水 | 直接冷却 | 3/8*4*2 | 780*260*650 | 68 |
| STC-12W | 95 | 12 | 1.5 | 80 | Direct | 3/8*6*2 | 780*260*650 | 70 | |
| STC-18W | 95 | 9*2 | 1.5 | 200 | Water | Cooling | 3/8*6*2 | 900*400*810 | 100 |
| STC-24W | 95 | 12*2 | 2.2 | 315 | 3/8*6*2 | 900*400*810 | 100 | ||
| STC-6 | 160 | 6 | 0.37 | 45 | 3/8*2*2 | 780*260*650 | 70 | ||
| STC-9 | 160 | 9 | 0.75 | 56 | 油 | 间接冷却 | 3/8*4*2 | 780*260*650 | 73 |
| STC-12 | 160 | 12 | 1.5 | 80 | Indirect | 3/8*6*2 | 780*260*650 | 75 | |
| STC-18 | 160 | 9*2 | 1.5 | 200 | Oil | Cooling | 3/8*6*2 | 900*400*810 | 110 |
| STC-24 | 160 | 12*2 | 2.2 | 315 | 3/8*6*2 | 900*400*810 | 110 | ||
| STCH-9W | 160 | 9 | 0.75 | 165 | 水 | 间接冷却 | 3/8*4*2 | 900*400*810 | 90 |
| STCH-12W | 160 | 12 | 1.5 | 235 | Indirect | 3/8*4*2 | 900*400*810 | 115 | |
| STCH-24W | 160 | 24 | 2.2 | 315 | Water | Cooling | 3/8*4*2 | 900*400*810 | 130 |
| STCH-9 | 300 | 9 | 0.55 | 45 | 油 | 间接冷却 | 3/8*4*2 | 900*400*810 | 120 |
| STCH-12 | 300 | 12 | 0.75 | 60 | Indirect | 3/8*4*2 | 900*400*810 | 140 | |
| STCH-24 | 300 | 24 | 1.5 | 165 | Oil | Cooling | 3/8*4*2 | 900*400*810 | 210 |
| STC-6W-2D | 95 | 6*2 | 0.37*2 | 45*2 | 水 | 直接冷却 Direct |
3/8*2*4 | 900*400*810 | 110 |
| STC-9W-2D | 95 | 9*2 | 0.75*2 | 56*2 | Water | Cooling | 3/8*4*4 | 900*400*810 | 115 |
| STC-6-2D | 160 | 6*2 | 0.37*2 | 45*2 | 油 | 间接冷却 Indirect |
3/8*2*4 | 900*400*810 | 120 |
| STC-9-2D | 160 | 9*2 | 0.75*2 | 56*2 | Oil | Cooling | 3/8*4*4 | 900*400*810 | 125 |
