| 型号 Model |
粉碎室口径 Chamber Calibre (mm) |
破碎能力 Crush Capacity (Kg/H) |
转刀/定刀 Rotating /Fixed Blade(Pcs) |
转速 Rotational Speed |
电机功率 Motor(Kw) |
风机功率 Blower |
外形尺寸 External Dimensions (L*W*H) |
重量 Weight (kg) |
| SG-2416-2B | 240*160 | 15-30 | / | 28 | 1.5 | 0.55 | 1020*400*1400 | 110 |
| SG-2416-2C | 240*160 | 15-30 | / | 28 | 1.5 | / | 1020*400*1400 | 110 |
| SG-2425-2B | 240*250 | 30-50 | / | 28 | 1.5 | 0.55 | 1020*400*1400 | 120 |
| SG-2425-2C | 240*250 | 30-50 | / | 28 | 1.5 | / | 1020*400*1400 | 120 |
| SG-2838-2B | 280*380 | 50-80 | / | 28 | 2.2 | 0.55 | 1020*500*1400 | 180 |
| SG-2838-2C | 280*380 | 50-80 | / | 28 | 2.2 | / | 1020*500*1400 | 180 |
| SG-4140-2B | 410*400 | 80-100 | / | 28 | 3 | 0.55 | 1400*550*1500 | 250 |
| SG-4140-2C | 410*400 | 80-100 | / | 28 | 3 | / | 1400*550*1500 | 250 |
| SG-180FET-2B | 200*180 | 30-50 | 9/2 | 280 | 1.5 | 0.55 | 1020*400*1115 | 120 |
| SG-180FET-2C | 200*180 | 30-50 | 9/2 | 280 | 1.5 | / | 1020*400*1115 | 120 |
| SG-240FET-2B | 200*240 | 50-80 | 12/2 | 280 | 1.5 | 0.55 | 1020*400*1115 | 160 |
| SG-240FET-2C | 200*240 | 50-80 | 12/2 | 280 | 1.5 | / | 1020*400*1115 | 160 |
| SG-300FET-2B | 200*360 | 50-100 | 15/2 | 280 | 2.2 | 0.55 | 1100*500*1200 | 200 |
| SG-300FET-2C | 200*360 | 50-100 | 15/2 | 280 | 2.2 | / | 1100*500*1200 | 200 |
| SG-180FE-2B | 200*180 | 30-50 | 9/2 | 280 | 1.5 | 0.55 | 1020*400*1115 | 120 |
| SG-180FE-2C | 200*180 | 30-50 | 9/2 | 280 | 1.5 | / | 1020*400*1115 | 120 |
| SG-240FE-2B | 200*240 | 50-80 | 12/2 | 280 | 1.5 | 0.55 | 1020*400*1115 | 160 |
| SG-240FE-2C | 200*240 | 50-80 | 12/2 | 280 | 1.5 | / | 1020*400*1115 | 160 |
